Salient Features:
- Cost-effective and versatile
- High accuracy 1.0% reading
- Non invasive, no moving parts, no pressure drop, no maintenance
- Easy and economical installation, no pipe cutting
- Wide measurement range 0.2 ~ 12m/s
- Wide pipe size range (DN 15 ~ 4570mm)
- Suitable for all commonly used pipe materials
- Bidirectional measurement. Totaliser display for net, positive and negative flow
- Ideal for both clean and opaque liquid flow measurement
Applications:
- Chemical, petrochemical and process industries
- Fertilizer industries
- Pharmaceutical industries
- Food and drug industries
- Sugar, beverage industries
- Paper and pulp industries
- Water and waste water management
- Dredging industries
- Mining industries
Technical Specifications
| Parameters | Single Path | Two Path | Four Path |
| General | |||
| Make | CBRO | ||
| Model | UFC250I | ||
| No. of Sensors | 2 | 4 | 8 |
| Operating principle | Transit time technology | Transit time technology | Transit time technology |
| Operating pressure | 20 kg/cm2 max | 20 kg/cm2 max | 20 kg/cm2 max |
| Application | Raw, clear, sewage water & homogeneous liquids | Raw, clear, sewage water & homogeneous liquids | Raw, clear, sewage water & homogeneous liquids |
| Transmitter | |||
| Power supply | 24 V DC ± 20% 110 V AC ± 15% 240 V AC ± 15% Solar powered | 24 V DC ± 20% 110 V AC ± 15% 240 V AC ± 15% Solar powered | 24 V DC ± 20% 110 V AC ± 15% 240 V AC ± 15% Solar powered |
| Velocity | ±12 m/sec. Bidirectional | ±12 m/sec. Bidirectional | ±12 m/sec. Bidirectional |
| Display | 2 lines, 16 characters LCD with backlight flow rate, velocity, totaliser | 2 lines, 16 characters LCD with backlight flow rate, velocity, totaliser | 2 lines, 16 characters LCD with backlight flow rate, velocity, totaliser |
| Units | User configurable English/Metric | User configurable English/Metric | User configurable English/Metric |
| Totaliser | FWD, NET, REV | FWD, NET, REV | FWD, NET, REV |
| Output – Analog | 4 – 20 mA Std.* | 4 – 20 mA Std.* | 4 – 20 mA Std.* |
| Accuracy | ±1% of reading @ rate >0.5 m/sec. | ±0.5% of reading @ rate >0.5 m/sec. | ±0.5% of reading @ rate >0.5 m/sec. |
| Repeatability | 0.2% of Span | 0.2% of Span | 0.2% of Span |
| Protection class | IP 65 | IP 65 | IP 65 |
| Dimensions | 251X190X96 mm | 500x400x300 mm | 500x400x300 mm |
| Weight | < 2.5 kg | < 4.5 kg | < 6.5 kg |
| Security | Keypad lockout, access code enabled | Keypad lockout, access code enabled | Keypad lockout, access code enabled |
| Self diagnostic feature | Available | Available | Available |
| Facility to measure and display each path velocity | NA | Available | Available |
| Ability to work even though one or more path does not work | NA | Available | Available |
| Flow and totaliser unit programmability | Available | Available | Provided |
| Password protection for configuration data | Available | Available | Available |
| Totaliser value retention in the event of power fail condition | Available | Available | Available |
| RS 485 Modbus RTU Protocol | Available | Available | Available |
| Lightening protection units | Available | Available | Available |
| Sensor | |||
| Suited temp. – Std. | -40oC to 1200C | -40oC to 1200C | -40oC to 1200C |
| Pipe size | 50 – 6000 mm dia | 350 – 6000 mm dia | 1000 – 6000 mm dia |
| Protection class | IP 65, IP 67, IP 68 | IP 65, IP 67, IP 68 | IP 65, IP 67, IP 68 |
| Sensor dimensions | 186 mm with 20 mm bore size | 186 mm with 20 mm bore size | 186 mm with 20 mm bore size |
| Weight | < 1.5 kg | < 1.5 kg | < 1.5 kg |
| Cable length | 6 m std. can be extended up to 300 m | 6 m std. can be extended up to 300 m | 6 m std. can be extended up to 300 m |
